0201mm Pad Inspection Capability

With dramatic improvement of accuracy & repeatability by S/W & H/W renovation, the MS-11 can precisely measure and inspect solder paste on Mini-LED chips as small as 0201mm, with a designated height of 30㎛.

25M High Resolution Camera with 4㎛/6㎛ Lens

MIRTEC has implemented a next-generation vision system featuring 4㎛/6㎛ high-resolution lenses for greater precision and stability in inspection.
Additionally, the CoaXPress interface enables high-speed inspection, while the 25M high-resolution camera provides a large field of view (FOV) for enhanced performance.

Large FOV

With a large field of view (FOV), a larger and clearer image can be captured in a single shot, reducing the number of images required. This enables faster and more accurate inspections.

Warpage-Free Inspection System

The degree of warpage or twisting in a PCB can be calculated and compensated during inspection.
Additionally, the warpage itself can be evaluated to determine whether the PCB meets quality standards.

Telecentric Lens

Many 3D SPI systems on the market use conventional lenses, which cause image distortion.
MIRTEC doesn't.

All of our 3D SPI systems are equipped with telecentric lenses, eliminating image errors caused by perspective distortion and ensuring highly precise 3D inspections.

Dual-Drive Linear Motor

The system is equipped with a dual-drive linear motor, enabling semiconductor-level repeatability in inspection.

Solder Repair System (Option)

MIRTEC's SRS (Solder Repair System) automatically repairs defective pads identified as having insufficient solder or no solder after inspection, using a solder dispenser integrated into the optical system.

Want to know more?

Please contact us if you want to know more abut the MS-11 system.
